Orbital Shaker BER1BF1
Orbital Shaker- Sea, Air, Door to Door Shipping
- 1 Year Warranty
- US & European Standards
Specifications
| Model | BER1BF1 |
| Shaking Mode | Cyclotron oscillation |
| Function | |
| --Amplitude | ϕ10mm |
| --Rotary Speed Range | 100~500rpm |
| --Rotary Speed Precision | ±1rpm |
| Structure | |
| --Out Shell | ABS |
| --Motor Type | Brushless motor |
| --Tray | Anodizing Aluminum |
| --Driving Mode | Four horizontal points |
| --Power Rating | 0.03kW |
| Controller | |
| --Cyclotron Control Mode | LCD, PID intelligent control |
| --Cyclotron Setting Mode | Rotary coding switch |
| --Speed Display Mode | LCD display |
| --Timer | 0 ~ 9999 min ( with timing function ) |
| --Operation Function | Fixed value operation, timing function, bidirectional automatic switchover, auto stop, quick stop start |
| --Speed Sensor | Hoare |
| --Additional Function | Deviation calibration, power-off memory |
| Safety Device | Intelligent low speed start, blocking protection |
| Specification | |
| --Exterior Size (W*L*H)(mm) | 365*450*222 |
| --Packing Size (W*L*H)(mm) | 470*550*325 |
| --Tray Size (mm) | 320*320 |
| --Load Per Tray | ≤5kg |
| --Tray Number | 1 |
| --Supply (50/60Hz) Current Rating | AC220V/0.14A |
| --NW/GW (kg) | 10/15 |
| Optional Type | Universal spring grid trayFlask Clip Tray 250ml*9/500ml*4 |
Features
1. Temperature setting, measuring, and running state show on one large LCD screen, with rotary encoder switch.2. The operating parameters can be remembered and protected. Automatically resume operation if the power supply cut off.
3. Speed control : intelligent brushless DC motor, high speed accuracy, slow start design, auto lock if speed out of control. adjustable starting speed to prevent the splash of shake flask liquid.
