Conductivity Meter BFU1BT1
Conductivity/do Meter- Sea, Air, Door to Door Shipping
- 1 Year Warranty
- US & European Standards
Specifications
| Model | BFU1BT1 |
| Cond. Measuring range | Conductivity: |
| Cond. Measuring range | (0.00~20.00)μS/cm, (20.0~200.0)μS/cm |
| Cond. Measuring range | (200~2000)μS/cm, (2.00~20.00)mS/cm |
| Cond. Measuring range | (20.0~200.0)mS/cm, |
| Cond. Measuring range | (200~2000)mS/cm (K=10) |
| Cond. Measuring range | TDS: (0 ~ 100)g/L |
| Cond. Measuring range | Salinity: (0 ~ 100)ppt |
| Cond. Measuring range | Resistivity: (0 ~ 100)MΩ·cm |
| Cond. Resolution | 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm |
| Cond. Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS |
| Cond. Temp. compensation range | (0 ~ 50)°C, auto |
| Cond. Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 |
| Cond. Reference Temp. | 25°C, 20°C, 18°C |
| DO Measuring range | (0-20.00)mg/L(ppm), (0-200.0)% |
| DO Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % |
| DO Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L |
| DO Response time | ≤30s (25°C, 90% response) |
| DO Residual current | ≤0.1 mg/L |
| DO Temp compensation | (0 ~ 45)°C, auto |
| DO Salinity compensation | (0 ~ 45) ppt, auto |
| DO Pressure compensation | (80 ~ 105) kPa, auto |
| DO Auto calibrationc | Air saturated by water, water saturated by air |
| DO Electrode type | Polarographic |
| Temp. Range | (-10 ~ 110)°C |
| Temp. Resolution | 0.1°C |
| Temp.Accuracy | 5 ~ 60°C: ±0.4°C Others: ±0.8°C |
| Others Display | 7-inch colored capacitive touch screen |
| Others Data storage | 1000 sets |
| Others Power | 12V/1A |
| Others Output | USB |
| Others Ambient Temp. | 15 ~ 30 °C |
| Others Ambient Humidity | ≤85% |
| Others IP grade | IP54 |
| Others Dimensions/N.W. | 215x170x37mm/600g |
| Others Shipping Size/G.W. | 470x430x72mm/3kg |
| Standard Accessaries | Cond. electrode (K=1), DO electrode, Temperature probe, DO filling solution, Power adapter, Manual |
Features
1. 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.2. Built-in microprocessor chips have Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
3. Auto recognition of 8 conductivity standard solutions with 2 kinds of options: Europe & USA, and China.
4. It has functions of ATC, auto salinity compensation and auto pressure compensation.
5. Polarographic DO electrode, short polarization time (3-5 minutes).
• It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phones are optional.
• Smart electrode status display to ensure accurate use.
• Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
