Orbital Shaker BSOT-303
- Sea, Air, Door to Door Shipping
- 1 Year Warranty
- US & European Standards
Our product is an accurately designed, microprocessor controlled with double Decker platform to save your valuable lab space. Three eccentric shaft balancing drive ensures shaking with uniform speed. Speed adjustment settings permit both gentle and vigorous shaking. Varieties of platforms are available for different glassware and vessels.
- Compact space-saving design fits easily in incubator and refrigerator
- Simultaneous display of speed, timer and operating mode
- Brushless DC motor ensures maintenance-free, reliable and quiet operation
- Electronic time switching clock controls time or continuous operation mode
Specification
Features
Applications
| Speed Range | 100-350 rpm (Linear) 100-500 (orbital) |
| Temperature | 4-40°C |
| Permissible Ambient Temperature | 5-40°C |
| Shaking Orbit | 10 mm |
| Permissible Relative Humidity | 80.00% |
| Timing Range | 1-1199 min |
| Motion | Orbital/Linear |
| Motor rating Input [W] | 28 |
| Motor rating output [W] | 15 |
| Maximum Load Capacity | 7.5 kg |
| Operation | Continuous/Timed |
| Overall Dimension | 420x370x100 mm |
| Display | LCD |
| Weight | 13.5 kg |
| Power | 30 W |
| Power Supply | 100-240 V, 50/60 Hz |
- Compact space-saving design fits easily in incubator and refrigerator
- Simultaneous display of speed, timer and operating mode
- Brushless DC motor ensures maintenance-free, reliable and quiet operation
- Electronic time switching clock controls time or continuous operation mode
- RS232 interface enables data logging & computer control
- Over speed detection and protection
- Accommodate a variety of platforms, non-slip rubber mat, conical flasks and other sample containers
Stability, Dissolution Studies, Liquid Extractions, Protein Precipitation, Small Peptide Synthesis, Dilutions
Operating Manual for BSOT-303
Download Operating Manual PDF1. Packing List
2. Models
3. Installation Instructions
4. Operating procedure
5. Troubleshooting
1. Packing List
Main unit x 1, Universal attachment x 1, Power cable x1, Quick Guide -1
2. Models
Large Multifunctional Linear Decolorizing Shaker (7.5Kg)Large Multifunctional Orbital Decolorizing Shaker (7.5Kg)
Multifunctional Linear Decolorizing Shaker (2.5Kg)
Multifunctional Orbital Decolorizing Shaker (2.5Kg)
3. Installation Instructions
1.Unpack the instrument carefully and place the instrument on a stable, clean, non-slip and fireproof surface.2.Ensure good working environment free of any combustible media or flammable materials to avoid additional hazards.
3.Place the shaker at >10cm distance from the wall and other units if using multiple units together.
4.Ensure that there is no accidental spillage during speed setting.
5.Do not use any combustible media or flammable materials to avoid any additional hazards.
6.Ensure that the label indicated the correct voltage before connecting the unit to power supply.
7.Do not operate the unit with a damaged power cord.
8.Disable the power supply while fitting the accessories.
9.Ensure that the unit and its accessories are in good working condition before each operation.
10.The instrument feet height can be adjusted to make sure its stable running.
4. Operating procedure
1. Switch power ON and the instrument starts to self-check.2. When initialization is over, LCD displays the last running values of speed.
3. Rotate the speed and time control knob to set target speed and time.
4. Press both adjustment knobs to start shaking.
5. When the timer reaches zero, the unit will be automatically halted.
5. Troubleshooting
1 . When switched ON, the instrument does not work◼ Check whether the power cable is connected.
◼ Check whether the fuse is broken.
2.Shaking speed can’t reach set value
◼ Check whether the load weight exceed the maximum load;
3.When press the timer button, the instrument doesn’t work.
◼ Check whether the time set value is “0”;
