Conductivity Meter BFU-4501
Conductivity/do Meter
Key Features
- 1. 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.
- 2. Built-in microprocessor chips have Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
- 3. Auto recognition of 8 conductivity standard solutions with 2 kinds of options: Europe & USA, and China.
- 4. It has functions of ATC, auto salinity compensation and auto pressure compensation.
- 5. Polarographic DO electrode, short polarization time (3-5 minutes).
- • It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phones are optional.
- • Smart electrode status display to ensure accurate use.
- • Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
SKU: BFU-4501
Old SKU: BFU1BT1
Pricing & Resources
- Up to 3-Year Product Warranty
- US & EU Compliance Standards
- Door-to-Door Shipping
Technical Specifications
Detailed operating and construction parameters for this model.
| Model | BFU-4501 |
| Conductivity : | |
| Conductivity Measuring range | Conductivity: (0.00~20.00)μS/cm, (20.0~200.0)μS/cm(200~2000)μS/cm, (2.00~20.00)mS/cm(20.0~200.0)mS/cm,(200~2000)mS/cm (K=10)TDS: (0 ~ 100)g/LSalinity: (0 ~ 100)pptResistivity: (0 ~ 100)MΩ·cm |
| Conductivity Resolution | 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm |
| Conductivity Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS |
| Conductivity Temp. compensation range | (0 ~ 50)°C, auto |
| Conductivity Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 |
| Conductivity Reference Temp. | 25°C, 20°C, 18°C |
| DO : | |
| DO Measuring range | (0-20.00)mg/L(ppm), (0-200.0)% |
| DO Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % |
| DO Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L |
| DO Response time | ≤30s (25°C, 90% response) |
| DO Residual current | ≤0.1 mg/L |
| DO Temp compensation | (0 ~ 45)°C, auto |
| DO Salinity compensation | (0 ~ 45) ppt, auto |
| DO Pressure compensation | (80 ~ 105) kPa, auto |
| DO Auto calibration | Air saturated by water, water saturated by air |
| DO Electrode type | Polarographic |
| Temperature : | |
| Temp. Range | (-10 ~ 110)°C |
| Temp. Resolution | 0.1°C |
| Temp.Accuracy | 5 ~ 60°C: ±0.4°C Others: ±0.8°C |
| Others Display | 7-inch colored capacitive touch screen |
| Others Data storage | 1000 sets |
| Others Power | 12V/1A |
| Others Output | USB |
| Other Ambient Temp. | 15 ~ 30 °C |
| Others Ambient Humidity | ≤85% |
| Others IP grade | IP54 |
| Others Dimensions/N.W. | 215x170x37mm/600g |
| Others Shipping Size/G.W. | 470x430x72mm/3kg |
| Standard Accessaries | Conductivity electrode (K=1), DO electrode, Temperature probe, DO filling solution, Power adapter, Manual |
Product Features
Key design, performance, usability, and safety advantages.
1. 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.
2. Built-in microprocessor chips have Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
3. Auto recognition of 8 conductivity standard solutions with 2 kinds of options: Europe & USA, and China.
4. It has functions of ATC, auto salinity compensation and auto pressure compensation.
5. Polarographic DO electrode, short polarization time (3-5 minutes).
It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phones are optional.
Smart electrode status display to ensure accurate use.
Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
