Conductivity Meter BFU-4101
Conductivity Meter
Key Features
- 1. 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.
- 2. Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB
- output, function settings, wireless printing, and self-diagnosis information, etc.
- 3. Adopting advanced conductivity measurement technology, with conductivity electrodes (K=1), it can meet measuring accuracy requirements for a range of 0.5μS/cm ~ 200mS/cm.
- 4. Can switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
- 5. Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China.
- 6. It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phones are optional.
- 7. Smart electrode status display to ensure accurate use.
SKU: BFU-4101
Old SKU: BFU1BP1
Pricing & Resources
- Up to 3-Year Product Warranty
- US & EU Compliance Standards
- Door-to-Door Shipping
Technical Specifications
Detailed operating and construction parameters for this model.
| Model | BFU-4101 |
| Conductivity : | |
| Conductivity Measuring range | Conductivity: (0.00~20.00)μS/cm, (20.0~200.0)μS/cm(200~2000)μS/cm, (2.00~20.00)mS/cm(20.0~200.0)mS/cm,(200~2000)mS/cm (K=10)TDS: (0 ~ 100)g/LSalinity: (0 ~ 100)pptResistivity: (0 ~ 100)MΩ·cm |
| Conductivity Resolution | 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm |
| Conductivity Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS |
| Conductivity Temp. compensation range | (0 ~ 50)°C, auto |
| Conductivity Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 |
| Conductivity Reference Temp. | 25°C, 20°C, 18°C |
| Temperature : | |
| Temp Range | (-10 ~ 110)°C |
| Temp Resolution | 0.1°C |
| Temp Accuracy | 5 ~ 60°C: ±0.4°C Others: ±0.8°C |
| Others Display | 7-inch colored capacitive touch screen |
| Others Data storage | 1000 sets |
| Others Power | 12V/1A |
| Others Output | USB |
| Others Ambient Temp. | 15 ~ 30 °C |
| Others Ambient Humidity | ≤85% |
| Others IP grade | IP54 |
| Others Dimensions/N.W. | 215x170x37mm/600g |
| Others Shipping Size/G.W. | 470x430x72mm/3kg |
| Standard Accessaries | Conductivity electrode (K=1), Temperature probe, Power adapter, Manual |
Product Features
Key design, performance, usability, and safety advantages.
1. 7-inch colored capacitive touch screen with high resolution (1024*600) and high sensitivity.
2. Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB
output, function settings, wireless printing, and self-diagnosis information, etc.
3. Adopting advanced conductivity measurement technology, with conductivity electrodes (K=1), it can meet measuring accuracy requirements for a range of 0.5μS/cm ~ 200mS/cm.
4. Can switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
5. Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China.
6. It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phones are optional.
7. Smart electrode status display to ensure accurate use.
8. Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
